Price List
1,654 parts — sorted by part number
1,654
Total Parts
1,566
With Pricing
This is a master parts list from Maico. Some items may no longer be available new. Call or email for availability of good used parts and pricing. Pricing subject to change without notice.
| Part # | Description | Price |
|---|---|---|
| 15 | Handle bar rubber bushing | $5.10 |
| 33 | Rear fender 77 (red) | $39.50 |
| 49 | Fork slider | $99.00 |
| 50 | Fork seal 36x47x7 | $13.75 |
| 64 | Main fork tube | $165.00 |
| 65 | 250 Cylinder head gasket | $12.30 |
| 72 | Steering stem nut | $10.80 |
| 73 | Fork cap cpl | $37.80 |
| 78 | Hexagon nut M 8, 14mm | $2.48 |
| 79 | Cyl gasket 250 square barrel | $3.95 |
| 80 | O ring 29 x 2.5 | $1.10 |
| 83 | Fork boot | $65.95 |
| 108 | Swing arn bush | $38.00 |
| 109 | Spacer tube | $8.80 |
| 110 | Swing arm spindle | $42.50 |
| 111 | Nut for swing arm spindle M 14x1.5 | $4.84 |
| 113 | Damper cpl girling | $110.00 |
| 115 | Ball race-inner | $15.50 |
| 116 | Ball race-outer | $15.50 |
| 118 | Crank seal-outer | $7.90 |
| 131 | Front fender | $49.50 |
| 133 | Lever pivot screw with nut | $2.80 |
| 141 | Rear fender | $49.50 |
| 145 | Clutch lever assy-old style | $46.50 |
| 146 | Brake lever assy-old style | $41.75 |
| 148 | Decompression lever cpl | $21.00 |
| 148A | Decompression lever only | $13.20 |
| 151 | Brake cam | $37.85 |
| 152 | Brake shoe small (pr) | $39.60 |
| 162 | Spoke 3.5x195 LG F. hub | $2.38 |
| 163 | Spoke nipple M 3.5 | $0.70 |
| 167 | Rim strap | $22.00 |
| 178 | Rear brake plate (casting) | $70.50 |
| 183 | Spacer bush for brake plate | $3.20 |
| 187 | Rubber washer | $0.60 |
| 188 | Rear brake shoe (PR)+B80 | $40.50 |
| 189 | Use P/N 1323 | call |
| 205 | Ball bearing 6303 2 RS C 3 | $21.00 |
| 208 | Spoke short 4x152 STL HUB | $2.30 |
| 209 | Spoke long 4x210 STL HUB | $2.30 |
| 210 | Spoke nipple M 4.0 | $0.90 |
| 211 | Sprocket 59T | $53.50 |
| 212 | Cable Adjusting screw with nut | $7.00 |
| 223 | Use P/N 7841 | call |
| 225 | Use P/N 8897 | call |
| 226 | Fork stop locking bolt | $9.40 |
| 235 | Brake rod | $15.40 |
| 236 | Extension spring | $5.50 |
| 237 | Clamp | $7.00 |
| 240 | Rear axle | $44.00 |
| 241 | Use P/N 9411 | call |
| 242 | Compression Spring | $4.05 |
| 243 | Wing nut | $10.00 |
| 244 | Nipple holder | $4.60 |
| 250 | Brake rod clevis securing clamp | $10.95 |
| 257 | Contact point bracket | $10.00 |
| 258 | Contact point arm | $10.00 |
| 260 | Primary Coil | $67.70 |
| 263 | Breather tube 4x1.5 | $2.96 |
| 277 | Sealing ring A 8x11.5 | $1.18 |
| 285 | Crank pin 250 | $29.60 |
| 288 | Sprocket 52 T | $69.50 |
| 289 | Nut rim lock | $2.96 |
| 298 | Exhaust flange gasket | $5.75 |
| 302T | Terrycable brake-small HUB | $32.95 |
| 303T | Terrycable clutch old case | $32.95 |
| 305 | Use P/N 315 | call |
| 308 | Air box thru 73 | $105.50 |
| 311T | Terrycable clutch 72-77 | $32.95 |
| 315 | Decompression cable | $16.75 |
| 316 | Head stay 250 Sq. Bl. | $18.80 |
| 318 | Cyl sleeve 250 Sq. Bl. | $140.90 |
| 319Y | Number plate F yellow | $11.00 |
| 323 | Identification plate | $3.30 |
| 325 | Rubber cable holder | $0.70 |
| 339 | Ball bearing 6303 CS | $15.90 |
| 342 | Air filter cover | $7.70 |
| 343 | Air boot | $25.51 |
| 348 | Clamp | $5.40 |
| 375 | Ball bearing 6206 2RS C3 | $22.20 |
| 386 | Sprint, stand | $4.05 |
| 388 | Rubber ring | $0.808 |
| 398 | Ignition Cover | $54.30 |
| 402 | Crankcase gasket 250 | $.80 |
| 403 | use P/N 707 | call |
| 406 | Ventilation hose | $4.40 |
| 407 | Copper sealing ring 6x10 | $1.10 |
| 408 | Oil filler plug 20x1..5 | $15.50 |
| 409 | Sealing ring 20x24 | $1.35 |
| 410 | Sealing ring 14x18 | $1.10 |
| 413 | Crank pin 25x48 | $27.40 |
| 414 | Crankshaft 501 | $874.50 |
| 423 | Rod bearing 25x31x17 | $34.50 |
| 424 | Needle bearing KBK 18x22x24 | $14.40 |
| 425 | Crankshaft bearing right 6305 | $26.50 |
| 426 | Crankshaft bearing right NU 305 C3 | $55.95 |
| 427 | Crank seal Sq. Bl. | $15.05 |
| 430 | Sealing ring 8x14x1 | $1.10 |
| 431 | Spacer crankshaft | $11.40 |
| 432 | Lock tab crankshaft | $1.50 |
| 437 | Clutch lever-Radial | $22.10 |
| 438 | Kickstarter ratchet plate | $38.75 |
| 439 | Kickstarter ratchet pinion | $53.40 |
| 443 | Duplex primary chain 3/8x7/32 | $60.10 |
| 444 | Thrust washer | $6.50 |
| 445 | Bushing, clutch bronze | $7.40 |
| 447 | Lock plate for guide nut | $3.10 |
| 448 | Clutch guide nut | $10.05 |
| 449 | Cup spring | $2.45 |
| 457 | Fiber clutch disc SC | $25.70 |
| 458 | Steel friction disc SC | $28.30 |
| 459 | Inner disc | $12.40 |
| 460 | Terminal disc | $19.60 |
| 461 | Clutch clip | $5.90 |
| 462 | Clutch spindle | $58.05 |
| 463 | Spindle bolt | $5.90 |
| 464 | Clutch spindle seal ring | $1.35 |
| 465 | Use P/N 2898 | call |
| 467 | Exhaust flange | $42.10 |
| 475 | 400 Cylinder Sq. Bl. | $248.00 |
| 479 | Gasket-cyl base 360 | $3.74 |
| 480 | Head gasket 360-400 Sq. Bl. | $11.80 |
| 482 | Intake gasket | $4.40 |
| 484 | Felt pad | $1.10 |
| 486 | Front brake cable thru 79 | $12.80 |
| 486T | Terrycable F. brake thru 79 | $32.95 |
| 490 | Mainshaft 17T T | $114.30 |
| 492 | Retainer ring | $0.96 |
| 494 | Sleeve pinion 22T T | $131.10 |
| 497 | Layshaft 13T T | $94.5 |
| 498 | 3rd Gear LS 16T T | $78.90 |
| 499 | Ball bearing 6005 2RS | $22.40 |
| 501 | Oil seal 30x40x7 | $7.60 |
| 502 | Spacer pinion | $7.60 |
| 503 | Sprocket 12T 4 spd. | $26.55 |
| 504 | Use P/N 3254 | call |
| 505 | Crank nut | $7.99 |
| 506 | 3rd Gear MS 22T 4 | $56.80 |
| 507 | 1st Gear LS 20T T | $77.10 |
| 508 | 2nd Gear LS 18T 4 | $54.80 |
| 509 | Ball bearing mainshaft | $18.45 |
| 510 | Sleeve pinion bronze bush | $4.50 |
| 512 | 538 shim 24x16.2x.3 mm | $0.98 |
| 513 | Needle bearing H K 1612 | $16.46 |
| 514 | Needle bearing BK 1616 | $18.96 |
| 516 | 13T Sprocket 4 spd | $27.50 |
| 517 | Decompression rel valve cpl | $81.45 |
| 520 | Decompression spring | $7.28 |
| 521 | Valve | $8.48 |
| 522 | Piston Std 66.95 Wiseco | $184.20 |
| 523 | Piston Ring 67.00 | $89.10 |
| 524 | 14T Sprocket 4 spd | $27.45 |
| 527 | Mainshaft 14T S | $72.20 |
| 528 | 2nd Gear MS 18T 7 | $79.95 |
| 529 | 3rd Gear MS 21T 7 | $102.85 |
| 530 | 1st Gear LS 23T 7 | $77.10 |
| 531 | 2nd Gear LS 19T 7 | $77.75 |
| 532 | Piston ring 67.00 | $25.25 |
| 533 | Piston 76.93 | $206.50 |
| 534 | Piston ring 77.00 | $48.05 |
| 535 | Piston pin 18x58 | $21.26 |
| 535W | Piston Pin 18x63 | $13.75 |
| 536 | Circlip D18 | $1.10 |
| 536W | Write Pin Clip-Wiseco | $1.10 |
| 537 | Piston pin 18x66 | $25.20 |
| 538 | Layshaft shim .50mm | $1.10 |
| 539 | Alloy R. brake pedal | $52.80 |
| 540 | Brake pedal outside collar | $11.00 |
| 543 | Washer for brake pedal | $1.80 |
| 547 | Oil seal 52x32x7 | $15.35 |
| 548 | Crank seal radial 25x35x8 | $11.95 |
| 550 | Spacer washer | $1.14 |
| 555 | Use P/N 2327 | call |
| 555A | Shift lever-folding SC+B421 | $27.50 |
| 556 | Shift lever rubber | $7.70 |
| 557 | Shift shaft-old case | $39.60 |
| 563 | Pull rod-Sq. Bl. | $17.10 |
| 571 | Use P/N 2220 | call |
| 572 | O Ring Seal | $1.10 |
| 573 | Spring shaft return | $5.95 |
| 575 | Hook ratchet | $17.90 |
| 576 | Spring hooked ratchet | $6.85 |
| 578 | Kick Shaft cpl w/o gear | $96.95 |
| 579 | Locking plate | $0.70 |
| 582 | Spring tension lever | $0.90 |
| 586 | Use 586T or 586R | call |
| 586R | Shift fork type 4,7,U,K,U1 | $102.70 |
| 586T | Shift fork type T,S,TN | $102.70 |
| 587 | Spring ring | $1.10 |
| 589 | Ignition wire | $5.50 |
| 591 | Rubber plug | $1.40 |
| 592 | Rotor bolt | $4.40 |
| 596 | Condenser | $11.82 |
| 600 | Rubber sleeve | $2.10 |
| 609 | Points assy. | $15.20 |
| 615 | Carburetor housing | $68.85 |
| 620 | Clamp screw | $2.65 |
| 621 | Clamp nut | $1.45 |
| 622-2.70 | Needle jet 2.70 | $4.95 |
| 622-2.75 | Needle jet 2.75 | $4.95 |
| 622-2.85 | Needle jet 2.85 | $4.95 |
| 622-2.90 | Needle jet 2.90 | $4.95 |
| 624-150 | Main jet 150 | $5.50 |
| 624-155 | Main jet 155 | $5.50 |
| 624-160 | Main jet 160 | $5.50 |
| 624-165 | Main jet 165 | $5.50 |
| 624-170 | Main jet 170 | $5.50 |
| 624-175 | Main jet 175 | $5.50 |
| 624-180 | Main jet 180 | $5.50 |
| 624-185 | Main jet 185 | $5.50 |
| 624-190 | Main jet 190 | $5.50 |
| 624-195 | Main jet 195 | $5.50 |
| 624-200 | Main jet 200 | $5.95 |
| 624-205 | Main jet 205 | $5.95 |
| 624-210 | Main jet 210 | $5.95 |
| 624-215 | Main jet 215 | $5.95 |
| 626-35 | Pilot jet 35 | $11.85 |
| 626-40 | Pilot jet 40 | $11.85 |
| 626-45 | Pilot jet 45 | $11.85 |
| 626-50 | Pilot jet 50 | $11.85 |
| 626-55 | Pilot jet 55 | $11.85 |
| 626-60 | Pilot jet 60 | $11.85 |
| 626-65 | Pilot jet 65 | $11.85 |
| 626-70 | Pilot jet 70 | $11.85 |
| 626-72 | Pilot jet 72 | $11.85 |
| 626-75 | Pilot jet 75 | $11.85 |
| 626-78 | Pilot jet 78 | $11.85 |
| 626-80 | Pilot jet 80 | $11.85 |
| 631 | Idle screw | $4.75 |
| 632 | Spring | $0.77 |
| 633 | Float bowl | $32.10 |
| 635 | Seal ring | $0.39 |
| 636 | Float bowl gasket | $4.50 |
| 637 | Clip | $3.15 |
| 638 | Float | $17.95 |
| 640 | Float pin | $0.98 |
| 641 | Slide #1 | $66.50 |
| 642 | Jet needle | $3.98 |
| 643 | Needle clip | $2.65 |
| 647 | Screw | $1.14 |
| 648 | Adjusting screw | $2.94 |
| 649 | Nut | $0.79 |
| 650 | O-ring | $2.30 |
| 651 | Rubber boot | $1.10 |
| 652 | Use P/N 5035 | call |
| 655 | Ratchet spring | $2.20 |
| 656 | Kick klever rubber | $12.53 |
| 659 | O Ring 15x1.5 | $1.05 |
| 666 | Kickstarter return spring | $22.20 |
| 668 | Kick joint | $32.30 |
| 673 | Friction disc BC | $15.57 |
| 676 | Inner disc BC | $11.00 |
| 677 | Terminal disc BC | $18.45 |
| 681 | Alum spacer tube | $21.50 |
| 682 | Use P/N 3143 | call |
| 683 | Clamp 40-60 | $4.76 |
| 692 | Wrist pin Bearing 501 | $33.90 |
| 693 | LS crankshaft bearing 3305 C3+B301 | $76.95 |
| 695 | Clutch Nut BC | $15.84 |
| 696 | Cyl sleeve 501 | $149.95 |
| 698 | Cyl base gasket 501 | $4.40 |
| 699 | Head gasket 501 | $17.60 |
| 707 | Gasket 4 spd clutch cover | $7.05 |
| 712 | Crank pin shim | $5.08 |
| 713 | Spacer, crank sprocket | $14.42 |
| 714 | Crankshaft sprocket | $79.90 |
| 717 | 400 Cyl sleeve Sq. Bl. | $99.76 |
| 720 | 400 Cylinder head gasket | $12.65 |
| 721 | Cylinder base gasket | $7.48 |
| 724 | Clutch guide BC | $70.15 |
| 725 | Clutch push pin | $41.59 |
| 726 | Clutch housing BC | $199.95 |
| 729 | Kickstarter ratcher | $91.74 |
| 730 | Kickstarter pinion | $118.90 |
| 731 | Ratchet spring | $1.76 |
| 732 | Spring cup | $2.64 |
| 733 | Spring clip | $1.76 |
| 734 | Main Shaft 14T K | $144.00 |
| 735 | Chain triplex primary 54L | $76.90 |
| 736 | Needle Bearing | $16.09 |
| 738 | 2nd Gear MS 14T K | $61.05 |
| 739 | Main shaft 17T U | $88.40 |
| 740 | 2nd Gear MS 20T U | $61.05 |
| 741 | Layshaft 13T U1 | $130.80 |
| 743 | 3rd Gear LS 16T U1 | $55.88 |
| 743 | Layshaft 13T U | $130.80 |
| 746 | 3rd Gear MS 22T U | $80.52 |
| 747 | 1st Gear LS 20T U | $77.60 |
| 749 | Spacer ring | $5.85 |
| 750 | Needle Bearing | $10.22 |
| 751 | Shift shaft BC | $66.40 |
| 753 | Pull Rod | $16.40 |
| 757 | Kickstarter shaft w/ gear | $131.40 |
| 758 | Kickstarter shaft only BC | $117.15 |
| 758A | Kickstarter shaft-threaded M18x2.5 | $116.15 |
| 761 | Quardrant gear | $161.70 |
| 762 | 2nd Gear LS 18T U1 | $79.80 |
| 784 | 3rd Gear MS 21T K | $101.80 |
| 785 | 1st Gear LS 23T K | $127.90 |
| 786 | 2nd Gear LS 19T K | $86.65 |
| 848 | Rubber foot rest | $7.90 |
| 857 | Key lock | $25.70 |
| 861 | Shim .15mm | $0.88 |
| 862 | Shim .20mm | $0.88 |
| 883 | Spacer bush | $4.10 |
| 888 | Clutch cover 125 | $72.40 |
| 889 | Clutch cover gasket 125 | $3.69 |
| 892 | Needle Bearing | $15.66 |
| 893 | Crankcase gasket 125 | $4.84 |
| 895 | Oil drain plug cpl | $18.40 |
| 896 | Packing cord 24" | $4.08 |
| 897 | Oil filler plug 125 | $15.90 |
| 905 | Needle bearing K 16x21x10 FV | $11.00 |
| 906 | Bearing L20 | $13.66 |
| 909 | Seal 28x38x7 | $10.15 |
| 911 | Idler gear | $46.35 |
| 913 | Needle bearing 16x21x10 | $23.40 |
| 914 | Use P/N 3893 | call |
| 919 | Rotary valve | $33.00 |
| 920 | Lock washer | $11.52 |
| 932 | Use P/N 1109 | call |
| 933 | Use P/N 1110 | call |
| 937 | Pressure plate guide | $6.16 |
| 938 | Sprocket | $49.55 |
| 945 | Clutch pressure plate | $19.80 |
| 946 | Push pin | $10.68 |
| 975 | Sprocket 14T | $46.90 |
| 976 | Sleeve pinion nut | $6.42 |
| 977 | Ball bearing 6302 | $18.31 |
| 978 | Bearing | $18.15 |
| 979 | Bearing 20x42x8 | $26.20 |
| 991 | Sprocket 17T | $48.10 |
| 994 | Hair pin spring | $1.64 |
| 1000 | O-ring 9.5x2.5 | $1.37 |
| 1004 | Kickstarter lever | $50.21 |
| 1013 | Kickstarter return spring | $6.60 |
| 1016 | Snap ring for cover | $1.18 |
| 1017 | O-ring 16x24x4 | $2.40 |
| 1019 | Circlip | $0.44 |
| 1020 | O-ring 14x17x1.5 | $1.81 |
| 1023 | Air boot 125 | $50.48 |
| 1031 | Sliding piece | $19.80 |
| 1032 | Rubber plate | $12.34 |
| 1035 | Use P/N 5395 | call |
| 1084 | Needle bearing 15x28x2 | $12.02 |
| 1096 | Spacer | $3.96 |
| 1097 | 125 Piston ring 54.00 | $33.00 |
| 1109 | Head gasket 125 | $7.05 |
| 1110 | 125 Cyl base gasket | $4.12 |
| 1112 | Exhaust gasket | $2.72 |
| 1121 | Rubber ring | $3.69 |
| 1123 | Nut for generator | $7700 |
| 1124 | Ignition coil | $47.80 |
| 1126 | Plug cap | $14.95 |
| 1129 | Carb rubber | $11.40 |
| 1135 | Sprocket 15T | $35.05 |
| 1136 | Sprocket 16T | $42.06 |
| 1138 | Isolation plate | $15.79 |
| 1139 | Sealing ring | $3.84 |
| 1147 | Piston ring 54.50 | $37.62 |
| 1166 | Rubber mount | $19.15 |
| 1249 | Silent block | $13.75 |
| 1263 | Gas cap seal | $2.98 |
| 1313 | Crank stuffer O-ring | $3.53 |
| 1322 | Front brake shoes EBC (PR) | $27.50 |
| 1323 | Tension spring | $10.95 |
| 1324 | Front brake lever | $26.40 |
| 1404 | Use P/N 1514 | call |
| 1406 | Countersunk screw M6x10 | $0.44 |
| 1416 | Countersunk rivet 6x22 | $0.97 |
| 1420 | Countersunk rivet 6x30 | $0.97 |
| 1421 | Washer 12x18x1 | $0.52 |
| 1424 | Crankcase gasket 125 | $4.40 |
| 1427 | Securing spring A 16x1 | $0.58 |
| 1438 | Securing ring A 12x1 | $0.35 |
| 1439 | Cylinder screw M 6x10 | $0.61 |
| 1447 | Washer 9x15x1 | $1.66 |
| 1465 | Stud M 5x4 | $0.53 |
| 1479 | Bearing 17x35x8 | $30.90 |
| 1480 | Seal ring 17x85x5 | $11.88 |
| 1498 | Screw M5.5x18 | $0.97 |
| 1500 | Hexagon screw M 6x40 | $0.55 |
| 1508 | Stud M 6x20 | $0.88 |
| 1509 | Spring ring | $9.03 |
| 1510 | Spring ring B 6 | $0.44 |
| 1511 | Spring ring B 8 | $0.48 |
| 1512 | Spring ring B 10 | $0.44 |
| 1513 | Counter sunk screw M 5x16 D 963 | $0.53 |
| 1514 | Countersunk screw M 6x10 | $0.53 |
| 1515 | Use P/N 1597 | call |
| 1517 | Socket screw M8x75 | $1.76 |
| 1519 | Cylinder screw 6x75 | $1.67 |
| 1521 | Use P/N 1595 | call |
| 1523 | Exhaust bolt M6x70 | $1.27 |
| 1525 | Hexagon screw M 6x14 | $0.88 |
| 1526 | Cylinder head screw M 8x10 | $0.99 |
| 1527 | Cylinder head screw M 4x10 | $0.27 |
| 1528 | Cylinder head screw M 4x16 | $0.53 |
| 1529 | Cylinder head screw M 5x10 | $0.53 |
| 1533 | Cylinder head screw M 6x18 | $0.60 |
| 1536 | Cylinder head screw M 6x25 | $0.53 |
| 1537 | Cylinder head screw M 6x28 | $0.62 |
| 1538 | Cylinder head screw M 6x35 | $0.66 |
| 1539 | Cylinder head screw M 6x40 | $0.73 |
| 1541 | Cylinder head screw M 6x50 | $0.79 |
| 1542 | Cylinder head screw M 6x55 | $0.88 |
| 1543 | Cylinder head screw M6x60 | $1.10 |
| 1544 | Cylinder head screw M6x65 | $0.97 |
| 1545 | Cylinder head screw M 6x80 | $1.43 |
| 1546 | Cylinder head screw M 6x85 | $1.76 |
| 1547 | Cylinder Head Screw M6x90 | $1.98 |
| 1550 | Cylinder head screw M 6x30 | $0.66 |
| 1564 | Hexagon screw M6x10 | $0.49 |
| 1565 | Hexagon screw M6x12 | $0.53 |
| 1567 | Hexagon screw M6x16 | $0.44 |
| 1568 | Hexagon screw M 6x18 | $0.62 |
| 1569 | Hexagon screw M 6x20 | $0.51 |
| 1570 | Hexagon screw M 6x25 | $0.55 |
| 1571 | Hexagon screw M 6x30 | $0.53 |
| 1572 | Hexagon screw M 6x35 | $0.66 |
| 1573 | Hexagon screw M 6x50 | $0.97 |
| 1574 | Hexagon screw M 6x54 | $0.97 |
| 1575 | Hexagon screw M 6x60 | $1.10 |
| 1579 | Hexagon screw M 6x80 | $1.23 |
| 1580 | Hexagon screw M 6x45 | $0.66 |
| 1584 | Hexagon screw M 7x20 | $0.66 |
| 1585 | Hexagon screw M 8x10 | $0.66 |
| 1587 | Hexagon screw M 8x16 | $0.66 |
| 1589 | Hexagon screw M 8x20 | $0.80 |
| 1591 | Hexagon screw M 8x25 | $0.75 |
| 1592 | Hexagon screw M 8x30 | $0.75 |
| 1593 | Hexagon screw M 8x35 | $0.84 |
| 1594 | Hexagon screw M 8x40 | $0.75 |
| 1595 | Hexagon screw M 8x45 | $0.80 |
| 1596 | Hexagon screw M 8x50 | $0.84 |
| 1597 | Hexagon screw M 8x55 | $0.84 |
| 1598 | Hexagon screw M 8x60 | $0.97 |
| 1599 | Hexagon screw M 8x60 | $0.75 |
| 1600 | Hexagon screw M 8x65 | $1.14 |
| 1601 | Hexagon screw M 8x70 | $1.23 |
| 1604 | Hexagon screw M 8x90 | $0.99 |
| 1610 | Engine mount bolt M8x120 | $5.54 |
| 1618 | Hexagon screw M 10x50 | $4.24 |
| 1619 | Hexagon screw M 10x55 | $1.32 |
| 1626 | Hexagon screw M 10x1.5x60 | $1.10 |
| 1628 | Socket screw M 8x25 | $1.32 |
| 1629 | Use P/N 1646 | call |
| 1630 | Socket screw M 5x16 | $0.46 |
| 1631 | Socket screw M 5x16 | $0.44 |
| 1633 | Socket screw M 5x16 | $0.53 |
| 1635 | Socket screw M 6x25 | $0.44 |
| 1638 | Socket screw M 6x50 | $1.23 |
| 1646 | Socket screw M 8x30 | $0.66 |
| 1647 | Socket screw M 8x35 | $0.71 |
| 1648 | Socket screw M 8x40 | $0.97 |
| 1649 | Socket screw M 8x45 | $1.59 |
| 1650 | Socket screw M 8x12 | $1.06 |
| 1652 | Socket screw M 8x20 | $0.66 |
| 1655 | Socket screw M 10x25 | $1.100 |
| 1657 | Socket screw M 10x40 | $1.65 |
| 1661 | Socket screw M 10x50 | $2.73 |
| 1665 | Hexagon nut M 4 | $0.24 |
| 1666 | Hexagon nut M 5 | $0.24 |
| 1667 | Hexagon nut M 6 | $0.18 |
| 1670 | Hexagon screw M 8 | $0.26 |
| 1674 | Hexagon nut M 10x1.5 | $0.66 |
| 1675 | Hexagon nut M 10x1.25 | $0.66 |
| 1676 | Hexagon nut M 10 flat | $0.88 |
| 1677 | Hexagon nut M 10x1.0 | $0.71 |
| 1683 | Hexagon nut M 16x1.5 | $2.20 |
| 1689 | Locknut M 5 | $0.26 |
| 1690 | Locknut M 6 | $0.33 |
| 1691 | Locknut M 7 | $0.77 |
| 1692 | Locknut M 8 | $0.46 |
| 1693 | Locknut M 10x1.5 | $0.79 |
| 1694 | Securing nut M 10x1.0 | $0.97 |
| 1698 | Flange nut M 8 | $0.66 |
| 1700 | Securing nut M 8 | $0.88 |
| 1702 | Lock nut M 4 | $0.10 |
| 1704 | Lock nut M 6 | $0.11 |
| 1705 | Lock nut M 8 | $0.13 |
| 1706 | Lock nut M 10x1.25 Din 98 | $0.18 |
| 1709 | Hexagon nut NM 16x1.5 | $7.04 |
| 1711 | Spring washer M 5 | $0.07 |
| 1712 | Spring washer M 6 | $0.11 |
| 1713 | Spring washer M 7 | $0.13 |
| 1714 | Spring washer M 8 | $0.18 |
| 1715 | Spring washer M 10 | $0.29 |
| 1718 | Spring washer M 14 | $0.40 |
| 1719 | Securing nut M 4 | $0.53 |
| 1726 | Washer A 6.4 | $0.26 |
| 1727 | Securing nut M 12x1.5 | $1.23 |
| 1728 | Flat washer D 3.2 | $0.07 |
| 1731 | Flat washer D 5.3 | $0.11 |
| 1732 | Flat washer D 6.4 | $0.22 |
| 1734 | Flat washer D 8.4 | $0.11 |
| 1735 | Flat washer D 10.5 | $0.18 |
| 1737 | Flat washer D 13 | $0.22 |
| 1741 | Washer A 5.3 | $0.44 |
| 1742 | Washer B 4.3 | $0.26 |
| 1745 | Washer B 8.2x20 | $0.53 |
| 1747 | Washer 8.4x15x1.5 | $0.53 |
| 1749 | Washer 8.4x25x2 | $1.65 |
| 1750 | Washer M 6x20 | $0.33 |
| 1753 | Washer 12.2x30.2x0.5 | $0.97 |
| 1754 | Washer 15x25x2 | $0.44 |
| 1758 | Washer 25x10x2 | $0.44 |
| 1759 | Washer B 8.4 | $0.62 |
| 1762 | Pan head screw M 5x10 | $0.26 |
| 1768 | Stud M 6x42 | $1.38 |
| 1772 | Stud M 8x25 | $1.10 |
| 1774 | Stud M 8x40 | $2.31 |
| 1780 | Stud M 10x50 | $1.49 |
| 1782 | Stud M 10x45 | $1.76 |
| 1783 | Use P/N 8576 | call |
| 1784 | Stud M 5x6 | $0.53 |
| 1787 | Stud M 8x28 | $3.85 |
| 1788 | Cylinder head screw M 5x6 | $1.65 |
| 1795 | Counter sunk screw M 5x8 | $0.44 |
| 1803 | Rear sprocket bolt M 8x40 | $1.37 |
| 1810 | Countersunk screw M 5x20 | $0.66 |
| 1812 | Counter sunk screw M 6x16 | $0.77 |
| 1823 | Counter sunk screw M 6x80 | $1.43 |
| 1828 | Tension pin 5x26 | $0.53 |
| 1831 | Tension pin 6x10 | $0.79 |
| 1836 | Lock ring D 8x0.8 | $0.33 |
| 1838 | Securing washer | $0.33 |
| 1839 | Lock ring | $0.33 |
| 1840 | Lock ring D 9 | $0.44 |
| 1842 | Circlip 10x1.2 | $0.55 |
| 1848 | Sprocket circlip | $1.54 |
| 1849 | Retaining ring 32mm | $0.88 |
| 1850 | Circlip D 40x1.75 | $2.20 |
| 1853 | Circlip D 35x1 | $1.54 |
| 1857 | Split pin D 3x25 | $0.44 |
| 1863 | Use P/N 3053 | call |
| 1865 | Seal 12x22x7 | $7.65 |
| 1866 | Oil seal 18x28x7 | $8.85 |
| 1869 | Ball 1/8" | $0.22 |
| 1873 | Ball D 6 | $0.33 |
| 1874 | Ball D 7 | $0.53 |
| 1875 | Securing ring 88x3 | $5.54 |
| 1877 | Oval head screw M 3x8 | $0.26 |
| 1878 | Countersunk screw M 6x16 | $0.53 |
| 1879 | Circlip, sprocket 83-on | $0.88 |
| 1880 | Flat head sprocket bolt M 8x50 | $1.54 |
| 1881 | Woodruff key 3x3.7 | $0.77 |
| 1882 | Woodruff key 4.5 | $0.97 |
| 1883 | Woodruff key 4x6.5 | $1.06 |
| 1884 | Securing ring | $5.11 |
| 1891 | Oil sealing ring | $2.20 |
| 1897 | Securing ring 32x1.5 | $1.32 |
| 1900 | Oval head nail D 2x4 | $0.35 |
| 1901 | Oval head neil 3x8 | $0.35 |
| 1902 | O-ring 45x2.5 | $1.32 |
| 1903 | Pin D 8x20 | $1.32 |
| 1906 | Oval head rivet 4x10 | $0.29 |
| 1915 | Nipple M 6 | $1.32 |
| 1920 | Transmission shim .2 | $0.88 |
| 1921 | Layshaft shim .15mm | $1.10 |
| 1930 | O-ring 20x4 | $1.67 |
| 1931 | Inner bush swing arm >84 | $22.70 |
| 1932 | Guide plate on swing arm | $7.60 |
| 1933 | Chain guide RH | $7.60 |
| 1934 | Chain guide LH | $7.60 |
| 1935 | Plastic guide | $7.50 |
| 1936 | Bush for roller | $7.84 |
| 1937 | Chain roller | $10.45 |
| 1964 | Decal "M" 4.5" | $8.80 |
| 1977 | Brake rod | $24.20 |
| 1978 | Rear brake arm | $38.23 |
| 1983 | Sprocket cover | $30.40 |
| 1984 | Use P/N 408 | call |
| 1985 | Vent nipple | $8.36 |
| 1986 | Bearing lock plate | $9.45 |
| 1987 | Crankshaft housing | $37.60 |
| 1988 | Chain bearing lock plate | $8.80 |
| 1989 | Ignition case gasket | $4.40 |
| 1990 | Clutch gasket | $8.36 |
| 1991 | Ignition cover black | $41.80 |
| 1993 | Center case gasket | $7.48 |
| 1994 | Engine bush rear | $13.20 |
| 1995 | Engine bush front | $5.18 |
| 1997 | Inner ring | $6.88 |
| 2001 | Rim band 21" | $4.84 |
| 2002 | Tube 3.00x21 | $25.70 |
| 2003 | Tire 3.00x21" | $94.05 |
| 2005 | Rim band 18" | $4.80 |
| 2008 | Tire 4.5x18 | $117.20 |
| 2015 | Tube 4.5x18 | $26.40 |
| 2025 | Mainshaft | $89.35 |
| 2037 | Output shaft 28T | $135.90 |
| 2038 | Plug | $2.97 |
| 2039 | 5th gear on mainshaft 28T | $59.85 |
| 2043 | Spacer washer | $7.26 |
| 2044 | Spacer ring | $11.90 |
| 2049 | 5th gear on mainshaft 29T | $65.10 |
| 2058 | Piston 67.71 | $175.80 |
| 2059 | Piston 1st oversize 67.10 | $193.20 |
| 2060 | Piston 2nd oversize 67.25 | $193.20 |
| 2060W | Piston 67.20 Wiseco | $184.35 |
| 2061 | Piston 3rd oversize 67.40 | $193.20 |
| 2062W | Piston 67.45 Wiseco | $184.35 |
| 2063 | Use P/N 2465 | call |
| 2064 | Piston ring 1st oversize 67.15 | $73.27 |
| 2065 | Piston ring 2nd oversize 67.30 | $45.70 |
| 2065W | Piston 67.25 Wiseco | $22.76 |
| 2066 | Piston ring 3rd oversize 67.45 | $73.27 |
| 2066W | Piston Ring 67.5 Wiseco | $25.24 |
| 2067 | Piston ring 3rd oversize 67.60 | $65.10 |
| 2067W | Piston ring 67.60 Wiseco | $22.04 |
| 2069 | Piston 1st oversize 77.09 | $201.20 |
| 2070 | Piston 2nd oversize 77.23 | $201.20 |
| 2071 | Piston 3rd oversize 77.40 | $201.20 |
| 2072 | Piston 4th oversize 77.53 | $297.00 |
| 2072W | Piston 77.50 Wiseco | $190.30 |
| 2076 | Piston ring 1st oversize 77.15 | $4805 |
| 2078 | Piston ring 3rd oversize 77.45 | $48.05 |
| 2079 | Piston ring 4th oversize 77.60 | $48.05 |
| 2101 | Piston Ring 76.95 | $48.05 |
| 2110 | Piston std. 81.92 wiseco | $208.00 |
| 2111 | Piston Ring 82.00 | $70.20 |
| 2111W | Piston ring 82.00 Wiseco | $35.20 |
| 2112 | Use P/N 2473 | call |
| 2113 | Piston ring 1st oversize 82.15 | $51.45 |
| 2114 | Use P/N 2474 | call |
| 2115 | Piston ring 2nd oversize 82.30 | $88.70 |
| 2116 | Use P/N 2474 or 2118 | call |
| 2117 | Piston ring 3rd oversize 82.45 | $88.70 |
| 2118 | Piston 4th oversize 82.52 | $207.00 |
| 2118W | Piston 82.42 Wiseco | $218.00 |
| 2119 | Piston ring 4th oversize 82.60 | $87.80 |
| 2119W | Piston ring 82.50 Wiseco | $35.00 |
| 2120 | Use P/N 2476 or 2477 | call |
| 2121 | Piston ring 82.9 | $87.80 |
| 2133 | Sliding piece, plastic | $24.04 |
| 2140 | Clutch cover | $149.00 |
| 2146 | Chain protector GS | $34.85 |
| 2148 | Grip R Magura | $9.47 |
| 2156 | Cylinder head 250 | $138.37 |
| 2157 | 400 cyllinder 78-80 | $456.50 |
| 2159 | Cylinder sleeve 400 78-81 | $198.25 |
| 2160 | Cylinder head Radial | $198.00 |
| 2169 | Lock ring | $2.53 |
| 2171 | 78-79 Magnum fork seal | $11.35 |
| 2172 | Seal ring M 40 | $1.32 |
| 2184 | Air valve cpl | $7.15 |
| 2186 | Valve core | $3.87 |
| 2187 | Air valve cap | $3.87 |
| 2204 | Lever cover red | $8.25 |
| 2211 | Throttle stop adjusting screw | $3.78 |
| 2212 | Rubber cap | $5.72 |
| 2213 | Clutch lever bracket | $16.50 |
| 2215 | Use P/N 8522 | call |
| 2216 | Clutch lever blade-magura | $30.85 |
| 2217 | Brake lever bracket | $35.41 |
| 2218 | Use P/N 8523 | call |
| 2219 | Brake lever blade-magura | $24.75 |
| 2220 | Kill button cpl | $18.70 |
| 2221 | Rubber cap | $3.74 |
| 2228 | Gas cap | $24.25 |
| 2228V | Gas cap W vent tube | $26.64 |
| 2233 | Hub-front | $157.85 |
| 2236 | Front brake plate | $63.25 |
| 2237 | Cylinder head gasket 0.7 thick | $8.25 |
| 2238 | Brake plate bush | $5.94 |
| 2242 | Spoke nipple M 4.0 | $1.65 |
| 2247 | Front axle cpl | $49.95 |
| 2250 | Spacer bush | $9.36 |
| 2264 | Side panel 78 L-falk | $41.36 |
| 2271 | Side panel 78 R-falk | $41.36 |
| 2275 | Isolation hose 8x0.7 | $2.53 |
| 2278 | Cylinder head stay-L 250 | $10.56 |
| 2324 | Washer 12.1x26.2x1 | $0.88 |
| 2326 | Pull rod | $22.45 |
| 2327 | Gear lever-folding | $70.63 |
| 2336 | Pullrod | $46.42 |
| 2374 | Pivot arm | $44.77 |
| 2376 | Sliding piece | $37.16 |
| 2388 | Spring hook | $10.91 |
| 2393 | Guide screw | $9.72 |
| 2395 | Tension spring | $1.93 |
| 2396 | Pawl pin | $18.85 |
| 2397 | Washer 10.6x18.2x1 | $2.97 |
| 2399 | Shift fork shaft | $16.86 |
| 2406 | Short mag rear spoke | $2.94 |
| 2407 | Spoke long mag rear 75-80 | $2.98 |
| 2408 | Spoke nipple M 4.5 | $2.55 |
| 2417 | Use P/N 5149 | call |
| 2418 | Brake pivot | $7.92 |
| 2419 | Brake toggle | $23.65 |
| 2427 | Bearing-front wheel 6202 RS | $10.78 |
| 2428 | Spacer tube | $15.29 |
| 2430 | Threaded bush | $11.18 |
| 2432 | Front spokes M 4x230 | $2.53 |
| 2433 | Front spokes M 4x243 80 | $2.53 |
| 2434 | Rim lock rear | $20.02 |
| 2436 | Piston ring 1st oversize 77.20 | $80.46 |
| 2437 | Piston ring 2nd oversize 77.40 | $48.05 |
| 2439 | Piston ring 4th oversize 77.80 | $80.46 |
| 2440 | Piston ring 5th oversize 78.00 | $48.05 |
| 2454 | Cable bush | $1.76 |
| 2456 | Throttle cable Magura 311 | $13.20 |
| 2456AT | Terrycable old throttle | $32.95 |
| 2456AT | Terrycable for Magura 311 | $32.95 |
| 2461 | Piston 1st oversize 67.15 | $206.70 |
| 2462 | Piston 2nd oversize 67.35 | $206.70 |
| 2464 | Piston 4th oversize 67.75 | $203.70 |
| 2464W | Piston 67.70 Wiseco | $184.55 |
| 2465 | Piston 67.95 Wiseco | $184.55 |
| 2465.1 | Piston 68.2 Wiseco | $184.55 |
| 2465.2 | Piston 68.45 Wiseco | $184.55 |
| 2465.3 | Piston 68.95 | $184.55 |
| 2467 | Piston 1st oversize 77.13 | $238.37 |
| 2468 | Piston 2nd oversize 77.33 | $238.37 |
| 2470 | Piston 4th oversize 77.93 | $238.37 |
| 2471 | Piston 5th oversize 77.93 | $238.37 |
| 2471W | Piston 78.00 Wiseco | $214.50 |
| 2471.1W | Piston 78.50 Wiseco | $214.50 |
| 2471.2W | Piston 79.00 Wiseco | $214.50 |
| 2473 | Piston 1st oversize 82.12 | $314.60 |
| 2474 | Piston 2nd oversize 82.32 | $314.60 |
| 2476 | Piston 4th oversize 82.72 | $226.77 |
| 2477 | Piston 5th oversize 82.92 | $225.50 |
| 2477.1 | Piston 83.42 Wiseco | $255.50 |
| 2477.2 | Piston 83.92 Wiseco | $255.50 |
| 2481 | Seat cpl 72-76 | $121.00 |
| 2483 | Seat cover thru 76 | $62.15 |
| 2485 | Rubber ring for filter box | $6.93 |
| 2499 | Cylinder sleeve 250 radial | $145.30 |
| 2500A | Cylinder sleeve 250 radial | $141.40 |
| 2503 | Shift shaft | $73.66 |
| 2508 | Guide plate | $7.92 |
| 2509 | Kickstarter Shaft SC 4 spd. | $114.55 |
| 2510 | Hooked ratchet T1 | $6.93 |
| 2512 | Grip L Magura | $9.40 |
| 2513 | Idler gear shaft | $14.50 |
| 2531 | Transformer | $35.86 |
| 2559 | Kick shaft 78-82 | $116.60 |
| 2566 | Use P/N 2559 + 761 | call |
| 2567 | Tire holder rear | $25.08 |
| 2568 | Tire holder front | $25.08 |
| 2580 | Clutch Body | $165.74 |
| 2582 | Head gasket 450CC | $13.20 |
| 2591 | 440 Cylinder cpl with exhaust manifold | $348.50 |
| 2593 | Cylinder head 440 | $170.50 |
| 2607 | Isolation hose | $0.70 |
| 2708 | Rubber washer | $2.44 |
| 2721 | Worm for speed drive | $41.68 |
| 2745 | Head gasket MD 250 | $8.62 |
| 2753 | Crank nut 125 | $8.85 |
| 2756 | Gasket for cover plate | $5.74 |
| 2763 | Grankcase gasket | $10.29 |
| 2766 | Cover gasker right | $4.40 |
| 2769 | Seal ring 32x52x6.5 | $13.75 |
| 2770 | Duplex chain | $72.16 |
| 2771 | Chain guide | $9.24 |
| 2798 | Seal ring | $10.83 |
| 2799 | Securing ring | $2.20 |
| 2828 | Rubber damper | $4.40 |
| 2831 | Petcock thru 79 | $28.60 |
| 2831A | Petcock 90 Deg. | $28.60 |
| 2832 | Fuel line clip | $3.30 |
| 2843 | Rear brake lever | $30.80 |
| 2856 | Damper rubber | $21.75 |
| 2865 | Rear axle | $19.60 |
| 2882 | Throttle MD 250 | $49.30 |
| 2883 | Clutch cable | $16.50 |
| 2890 | Washer 10.1x18.2x0.6 | $0.77 |
| 2898 | Clutch lever | $20.46 |
| 2899 | Chain duplex 52L | $54.90 |
| 2931 | Selector key | $32.80 |
| 2937 | Bearing 6205 | $22.82 |
| 2944 | Use P/N 5594 | call |
| 2947 | Chain, triplex 52L | $71.00 |
| 2967 | Cylinder head stud | $8.26 |
| 2968 | Cylinder head stud | $4.78 |
| 2969 | Gasket, ignition cover | $6.77 |
| 2982 | Crankshaft CPL | $404.80 |
| 3004 | Base gasket 0.3 thick | $13.11 |
| 3008 | Head light ring | $52.13 |
| 3030 | Brake light switch | $21.90 |
| 3044 | Intake hose | $27.50 |
| 3045 | Rear brake plate | $79.60 |
| 3047 | Mirror | $48.80 |
| 3049 | Drive chain 120L | $115.80 |
| 3053 | Seal ring 20x30x4 | $15.84 |
| 3058 | Rotor support washer | $3.12 |
| 3059 | Socket screw M 8x1 LH | $2.09 |
| 3061 | Spring ring D 19x1.2 | $3.08 |
| 3071 | Piston cpl "A" | $218.90 |
| 3072 | Pistonn ring 75.994 | $92.07 |
| 3073 | Piston cpl "B" | $218.90 |
| 3093 | Use P/N 1934 | call |
| 3094 | Spacer 3.5x16x20 L | $5.72 |
| 3111 | Thrust washer 0.3 | $2.20 |
| 3124 | Protection cap | $20.24 |
| 3143 | Spacer tube | $18.28 |
| 3152 | Thrust washer 0.3 | $1.10 |
| 3164 | Air filter frame | $52.14 |
| 3168 | Carb cover plate | $16.06 |
| 3180 | Air box 74-75 | $60.50 |
| 3181 | Foam air filter thru 79 | $27.04 |
| 3182 | Air box flange | $23.76 |
| 3186 | Rear brake plate cpl | $172.50 |
| 3187 | Rear brake plate only | $117.95 |
| 3188 | Cover plate | $36.30 |
| 3189 | Pivot bolt | $15.40 |
| 3190 | Brake lever rear | $52.17 |
| 3196 | Wheel hub spacer | $14.08 |
| 3198 | Spoke M 4x140x60 | $2.94 |
| 3199 | Spoke M 4x195x45 | $2.94 |
| 3203 | Sprocket | $58.30 |
| 3220 | Duplex sprocket | $62.70 |
| 3223 | Brake rod, silver | $18.42 |
| 3225 | Crankcase cpl 250 | $451.00 |
| 3227 | Rear wheel sprocket 56 T | $71.50 |
| 3240 | Crankshaft nut | $5.94 |
| 3241 | Shift shaft 125 | $54.85 |
| 3244 | Ball bearing 6203-2RS | $15.92 |
| 3254 | Lock washer | $4.40 |
| 3257 | Cable rubber | $1.10 |
| 3258 | Crankcase cpl 400 | $524.92 |
| 3261 | Silent block | $10.12 |
| 3263 | Mount for speedometer | $27.94 |
| 3270 | Use P/N 1657 | call |
| 3276 | Distance spacer 115mm | $22.50 |
| 3277 | Rear axle completel 75-81 | $49.00 |
| 3280 | Hexagon screw M 7x40 | $0.88 |
| 3292 | Clutch spring | $2.30 |
| 3293 | Washer | $8.98 |
| 3296 | Nilos ring | $11.07 |
| 3297 | Steering bearing | $23.60 |
| 3300 | Light switch | $26.36 |
| 3304 | Speed o drive 77-79 | $75.00 |
| 3317-312 | Needle jet 3.12 | $6.91 |
| 3317-314 | Needle jet 3.14 | $6.91 |
| 3317-316 | Needle jet 3.16 | $6.91 |
| 3317-324 | Needle jet 3.24 | $6.91 |
| 3317-326 | Needle jet 3.26 | $6.91 |
| 3331 | Shock for float needle | $1.80 |
| 3333 | Throttle slide MD 250 | $23.20 |
| 3334 | Jet needle MD 250 | $3.96 |
| 3353 | Inside ring 12x16x12 | $24.90 |
| 3356 | Gasket, clutch cover | $7.70 |
| 3359 | Fork seal 38x50 | $9.35 |
| 3366 | Retaining ring 34x1.5 | $1.76 |
| 3367 | Damper insert | $11.88 |
| 3369 | Valve seat | $11.62 |
| 3375 | Spring ring 26 | $1.00 |
| 3389 | Clutch bush | $12.20 |
| 3390 | Inner clutch disc | $8.80 |
| 3391 | Terminal plate | $67.16 |
| 3396 | Clutch disc outer | $15.88 |
| 3397 | Tension ring | $13.00 |
| 3402 | Shift segment | $43.30 |
| 3406 | Gear rack cpl | $74.93 |
| 3410 | Hooked ratchet M | $9.10 |
| 3414 | Shift fork | $78.20 |
| 3415 | Pawl pin | $20.90 |
| 3416 | Locking screw | $10.80 |
| 3422 | Compression spring | $1.98 |
| 3423 | Ignition cover 125 | $34.10 |
| 3433 | Mainshaft "MG" | $113.00 |
| 3434 | 3rd gear MS 24T M | $94.65 |
| 3435 | 4th gear MS 26T M | $97.10 |
| 3438 | 1st gear LS 26T M | $97.10 |
| 3439 | 2nd gear LS 23T M | $93.80 |
| 3440 | 2nd gear MS 21T M | $101.90 |
| 3441 | 1st gear MS 19T M | $89.20 |
| 3442 | Twin gear LS 21/19T M | $104.20 |
| 3443 | 3rd gear MS 23T G | $160.70 |
| 3446 | 1st gear LS 28T G1 | $104.00 |
| 3447 | 2nd gear LS 24T G1 | $91.50 |
| 3448 | 2nd gear MS 20T G | $176.67 |
| 3449 | 1st gear MS 17T G | $104.70 |
| 3450 | Rwin block gear 21/18T G | $137.15 |
| 3454 | Sleeve pinion plug | $2.76 |
| 3456 | Washer 2nd gear | $0.99 |
| 3463 | Ball bearing-slv pinion 6005 2RS | $31.30 |
| 3465 | Sprocket 13T ( PN 851-13T ) | $26.95 |
| 3466 | Needle gauge 17x21x13 | $14.66 |
| 3469 | Crank seal 25x52x9 | $12.35 |
| 3471 | Kick shaft only - w/grooves | $116.00 |
| 3472 | Uses P/N 3472 + 761 | $278.70 |
| 3482 | Spacer bush for swing arm | $9.30 |
| 3488 | Swing arm plastic pad | $4.31 |
| 3491 | Swing arm axle | $48.10 |
| 3498 | Crankcase gasket | $9.90 |
| 3504 | Kickstarter shaft 125 | $95.20 |
| 3505 | Chain guide cpl | $102.75 |
| 3527 | Tank rubber pad | $4.62 |
| 3529 | Washer spacer | $3.52 |
| 3530 | Rubber sleeve for cable | $3.30 |
| 3563 | Foot peg | $28.05 |
| 3566 | Foot rest return spring R | $4.62 |
| 3568 | Foot rest return spring L | $4.62 |
| 3576 | Connector 6,3-1 | $1.00 |
| 3583 | Flat connector bush | $1.98 |
| 3595 | Connector 9.5D 46247 | $1.32 |
| 3596 | Isolation bush red 15-1` | $1.64 |
| 3597 | Isolation bush red 16-1` | $1.64 |
| 3598 | Use P/N 7599 | call |
| 3600 | Motoplat coil | $158.00 |
| 3630 | Clutch lever | $31.77 |
| 3697 | Head stay 250 thru 77 | $31.00 |
| 3706 | Spacer ring | $7.70 |
| 3708 | Chain 520z118 L | $122.55 |
| 3709 | Side panel R-white 75 | $33.00 |
| 3710 | Side panel L-white 75 | $33.00 |
| 3711 | Plastic screw 6x22 | $1.89 |
| 3720 | Sprocket 14T ( PN 851-14T ) | $27.95 |
| 3721 | Sprocket 15T ( PN 851-15T ) | $27.95 |
| 3722-12T | Sprocket 12T ( PN 851-12T ) | $27.95 |
| 3722-11T | Sprocket 11T ( PN 851-11T ) | $27.95 |
| 3723 | Washer | $1.58 |
| 3736 | Speedo cable vdo drive | $18.00 |
| 3738 | Screw M 4.8x13 | $1.20 |
| 3757 | Needle cage K 20x24x12 | $17.14 |
| 3790 | Fork tube 75-78 | $147.50 |
| 3795 | Roller bearing | $43.94 |
| 3797 | Seal ring | $17.64 |
| 3805 | Cover for air filter ++++++++++ | $16.50 |
| 3830 | Clutch lock tab tool | $51.00 |
| 3867 | Compress spring for kickstarter | $5.50 |
| 3872 | Spacer bush cpl | $28.20 |
| 3880 | Rear wheel spacer 19.5 mm | $11.80 |
| 3882 | Puller for motoplat | $37.60 |
| 3889 | Chain protector GS | $43.26 |
| 3891 | Spacer roller | $8.46 |
| 3893 | Washer 16x27x1.0 | $4.75 |
| 3907 | Fork seal/wiper 76-77 | $25.04 |
| 3913 | Damper buffer ring | $2.64 |
| 3932 | Needle bearing swing arm HK 2030 | $20.74 |
| 3936 | Swing arm plastic pad AW | $10.25 |
| 3958MOR | Air box 76-77 | $83.00 |
| 3967 | 3th gear MS 23T R | $141.25 |
| 4081 | Crankshaft exchange 250 | $246.00 |
| 4083 | Crankshaft exchange 490 | $319.00 |
| 4086 | Connecting rod 250 | $161.00 |
| 4088 | Connecting rod 500 | $249.00 |
| 4089 | Crankshaft exchange 250LC | $247.00 |
| 4152 | Oval decal Yellow | $4.95 |
| 4153 | Oval decal Green | $4.95 |
| 4155 | Oval decal White | $4.95 |
| 4162 | Connecting rod cpl 400-490 | $198.50 |
| 4163 | Connecting rod cpl 250 | $193.50 |
| 4164 | Connecting rod cpl 501 | $319.00 |
| 5011 | Lock nut M 14x1.5 | $1.98 |
| 5015 | Buffer block chain tensioner | $12.40 |
| 5018 | Chain tensioner cpl | $41.50 |
| 5020 | Spring chain tensioner | $6.38 |
| 5023 | Cable bush | $5.30 |
| 5029 | Plastic spacer | $1.56 |
| 5031 | Lock nut M 10x1.25 | $1.65 |
| 5033 | Kickstarter Lever upper | $107.80 |
| 5034 | Kickstarter joint | $104.80 |
| 5035 | Kickstarter lever cpl | $154.00 |
| 5038 | Cylinder sleeve 250 | $151.45 |
| 5050 | Use P/N 8944 | call |
| 5093 | Brake pedal bush 6.5x12x28 | $4.84 |
| 5149 | Front brake plate only | $62.20 |
| 5160 | Tension spring exhaust | $10.95 |
| 5192 | Seat cpl 77-79 | $110.00 |
| 5193 | Seat base 77-80 | $68.00 |
| 5194 | Seat foam | $97.00 |
| 5195 | Use P/N 6527 | call |
| 5197 | Seat Bracket | $30.00 |
| 5204 | Foam seal 5x20 | $4.40 |
| 5323 | #1 Jet needle | $4.62 |
| 5325 | Air screw | $4.40 |
| 5326 | O-ring | $1.76 |
| 5327-1401 | Slide #140-1 | $44.75 |
| 5327-220 | Slide #220 | $35.35 |
| 5329 | Plastic screen | $3.87 |
| 5330 | Guide block | $5.50 |
| 5331 | Return spring type 55 | $2.11 |
| 5332 | Cover plate | $16.50 |
| 5333 | Float needle | $21.90 |
| 5334 | Clamp ring-carb | $11.20 |
| 5335 | Tickler button | $10.34 |
| 5336 | Tickler spring | $0.79 |
| 5337 | Cotter pin | $0.44 |
| 5339 | Carb bush 36 | $15.29 |
| 5342 | Carb bush 40 | $16.92 |
| 5343 | Pilot jet screen | $7.15 |
| 5344 | Bush | $7.15 |
| 5345 | Rubber washer 12x30x5 | $0.77 |
| 5358 | Rubber insert | $7.48 |
| 5360 | Connecting rod 125 | $170.50 |
| 5361 | Rotary valve cover cpl | $135.05 |
| 5364 | Rotary valve plate | $14.64 |
| 5365 | Rubber seal-intake | $6.38 |
| 5370 | Cylinder base gasket | $2.40 |
| 5396 | Use P/N 9125 | call |
| 5399 | Electronic box-Bosch | $141.50 |
| 5429 | Clamp SP 28/15 | $5.68 |
| 5430 | Asbestos washer 8x25x2 | $1.10 |
| 5453 | Silencer bush | $4.40 |
| 5474 | Clamp 35/15 | $8.68 |
| 5527 | Piston 53.96 | $172.00 |
| 5528 | Piston ring 54.00 | $52.10 |
| 5531 | Piston 34.11 | $172.00 |
| 5532 | Piston 55.23 | $172.00 |
| 5592 | Spring cup | $8.41 |
| 5593 | Spring clip | $1.23 |
| 5596 | Layshaft bearing | $27.45 |
| 5597 | Layshaft (MT 1) | $74.95 |
| 5598 | Layshaft bearing | $23.40 |
| 5625 | Spacer bush CEV | $8.65 |
| 5697 | Layshaft GT1 | $79.60 |
| 5708 | Exhaust manifold | $51.00 |
| 5718 | Clutch guide | $70.15 |
| 5720 | Push pin | $27.50 |
| 5721 | Terminal plate | $67.16 |
| 5726 | Piston ring 82.40 | $51.05 |
| 5728 | Piston ring 82.80 | $51.05 |
| 5729 | Piston ring 83.00 | $51.05 |
| 5729W | Piston ring 83.00 Wiseco | $35.00 |
| 5729.1W | Piston ring 83.50 Wiseco | $35.00 |
| 5729.2W | Piston ring 84.00 Wiseco | $35.00 |
| 6065 | O-ring 12.37x2.62 | $1.32 |
| 6130 | Clamp 17-25 | $2.53 |
| 6144 | Front brake plate cpl | $145.00 |
| 6145 | Brake lever front | $57.77 |
| 6147 | Brake anchor | $23.15 |
| 6148 | Use P/N 1323 | call |
| 6150 | Clutch cable cpl thru 82 | $15.50 |
| 6150T | Terrycable clutch 78-82 | $32.95 |
| 6151 | Cable holder | $3.85 |
| 6152 | Pin | $2.18 |
| 6153 | Clip | $0.99 |
| 6158 | Bearing bush | $.90 |
| 6161 | Tank emblem L >79 | $6.05 |
| 6162 | Tank emblem R >79 | $6.05 |
| 6184 | Piston ring 1st oversize 67.20 | $72.00 |
| 6184W | Piston ring 67.20 Wiseco | $25.84 |
| 6187 | Piston ring 2nd oversize 67.40 | $72.00 |
| 6187W | Piston ring 67.4 Wiseco | $25.84 |
| 6189 | Piston ring 4th oversize 67.80 | $72.00 |
| 6189W | Piston ring 67.75 Wiseco | $25.84 |
| 6189.1W | Piston ring 67.8 Wiseco | $25.84 |
| 6191 | Piston ring 5th oversize 68.00 | $72.00 |
| 6191W | Piston ring 68.00 | $25.84 |
| 6191.1W | Piston ring 68.25 Wiseco | $25.84 |
| 6191.2W | Piston ring 68.5 Wiseco | $25.84 |
| 6191.3W | Piston ring 69.00 Wiseco | $25.84 |
| 6220 | O-ring | $1.54 |
| 6222 | Fork tube | $178.00 |
| 6228 | Foot peg R cpl 79 (NLA) | $39.90 |
| 6234 | Foor peg L cpl 79 | $39.90 |
| 6243 | Side panel L 79 | $42.00 |
| 6247 | Cable guide cpl | $9.46 |
| 6252 | Front decal Green | $5.48 |
| 6253 | Plastic screw M 6x30 | $2.32 |
| 6255 | Lower cable clamp | $5.80 |
| 6256 | Clamp plate | $3.96 |
| 6257 | Cable holder cpl. | $6.96 |
| 6258 | Cable holder | $2.98 |
| 6261 | Front decal Yellow | $5.48 |
| 6265 | Spring nut | $0.88 |
| 6275 | Pressure spring | $10.95 |
| 6276 | Exhaust spacer | $5.33 |
| 6280 | Throttle cpl | $75.00 |
| 6287 | Use P/N 6705 | call |
| 6303 | Crankcase gasket | $8.40 |
| 6305 | Securing ring 52x2 | $2.98 |
| 6316 | Kick lever upper 125 | $44.60 |
| 6323 | Brake plate only | $77.50 |
| 6351-6D6 | Jet needle | $6.96 |
| 6351-8G2 | Needle jet 8G2 | $5.04 |
| 6424 | Valve seat | $4.72 |
| 6426 | Valve seat | $4.72 |
| 6427 | Damper insert | $23.07 |
| 6428 | Spring ring D38 | $1.10 |
| 6429 | Fork cap cpl | $29.05 |
| 6431 | Fork cap | $15.80 |
| 6436 | Guide bush | $25.50 |
| 6437 | Circlip SB46 | $7.69 |
| 6439 | Fork Seal 42 mm | $10.60 |
| 6440 | Spring ring 55x1.5 | $4.39 |
| 6441 | Wiper Fork 80-92 | $38.95 |
| 6442 | Damper tube | $44.09 |
| 6447 | Damper piston | $19.65 |
| 6448 | SHim 23.9x28.2x0.9 | $1.10 |
| 6449 | Retaining ring SW 24 | $0.77 |
| 6450 | Piston ring | $14.20 |
| 6452 | Stop spring soft | $3.96 |
| 6454 | Valve | $5.85 |
| 6456 | Washer 29.9x36.7x0.2 | $1.33 |
| 6457 | Circlip 37x1.5 | $1.56 |
| 6458 | Damper tube bush | $11.40 |
| 6459 | Seal ring 10x15 | $0.47 |
| 6460 | Stop spring hard | $3.96 |
| 6463 | Plug | $23.05 |
| 6464 | O-ring 29.74x3.53 | $2.20 |
| 6471 | Steering stem | $66.10 |
| 6473 | Upper cross head | $101.10 |
| 6474 | Steering head nut | $17.13 |
| 6475 | Screw plug | $7.26 |
| 6476 | Shim B 23 | $1.43 |
| 6477 | Lower handle bar clamp cpl | $19.80 |
| 6478 | Upper hander bar clamp | $10.50 |
| 6479 | Lower handle bar clamp | $16.75 |
| 6480 | Cover plate | $15.00 |
| 6493 | Use P/N 99044 | call |
| 6496 | Use P/N 99043 | call |
| 6498 | Handle bar low | $39.65 |
| 6501 | Brake rod | $22.30 |
| 6502 | Brake lever-rear 80 | $40.80 |
| 6505 | Space bush | $5.08 |
| 6507 | Use P/N 6508 | call |
| 6508 | Gas tank MC | $310.00 |
| 6509 | Pet cock | $29.88 |
| 6509 | Pet Cock 81 Up | $29.00 |
| 6510 | O-ring 12x2 | $0.66 |
| 6511 | Loop for tank holder | $8.25 |
| 6512 | Use set 99089 | call |
| 6513 | Use set 99089 | call |
| 6515 | Gas cap w/gasket | $28.58 |
| 6516 | Gas cap seal | $9.45 |
| 6517 | Breather tube | $3.74 |
| 6520 | Use P/N 5193 | call |
| 6525 | Seat cpl 80 | $110.00 |
| 6526 | Use P/N 5194 | call |
| 6527 | Seat cover 77-80 | $60.90 |
| 6530 | Front brake cable 80-84 | $13.20 |
| 6530T | Terrycable front brake cable | $32.95 |
| 6531 | Rubber tank buffer | $14.74 |
| 6532 | Decal MC 250 1980 | $4.40 |
| 6533 | Foot peg L 1980 | $50.50 |
| 6535 | Foot peg R 1980 | $19.00 |
| 6536 | Foot peg axle 19 80 | $4.40 |
| 6537 | Foot peg spring R | $10.36 |
| 6538 | Foot peg spring L | $10.36 |
| 6539 | Circlip 10mm | $1.78 |
| 6540 | Air filter wire 80-81 | $31.87 |
| 6545 | Air filter foam 80-81 | $29.40 |
| 6546 | Air box 1980 | $130.00 |
| 6547 | Screw M 4.2x16 | $0.33 |
| 6553 | Air filter tab | $3.85 |
| 6555 | Front No. panel | $27.85 |
| 6561 | Side panel L 1980 | $52.29 |
| 6563 | Side panel R 1980 | $52.29 |
| 6565 | Rubber plug | $3.38 |
| 6585 | Gear change lever cpl | $70.30 |
| 6590 | Shift lever rubber | $3.14 |
| 6591 | Shift shaft | $74.47 |
| 6598 | Cylinder head stay right | $16.00 |
| 6601 | Decal MC400 1980 | $4.40 |
| 6623 | Decal MC400 1980 | $4.40 |
| 6626 | Fork slider with bush | $197.40 |
| 6628 | Spacer bush | $10.85 |
| 6629 | Fork spring | $49.00 |
| 6630 | Fork slider only | $197.95 |
| 6631 | Fork slider cpl | $205.40 |
| 6632 | Damper tube | $73.24 |
| 6637 | Fork tube | $263.53 |
| 6640 | Lower cross head | $139.60 |
| 6642 | Washer D 10.5 | $0.44 |
| 6659 | Silent block | $6.60 |
| 6660 | Head stay left 490 | $13.91 |
| 6661 | Head stay right 490 | $13.91 |
| 6668 | Handle bar | $70.30 |
| 6669 | Rear fender 81-84 | $52.00 |
| 6670 | Front hub only | $208.90 |
| 6674 | Front spoke 4x227- 80 Deg. | $3.18 |
| 6675 | Front spoke 4x227-100 Deg. | $3.18 |
| 6676 | Front spoke 4x244-115 Deg. | $3.18 |
| 6687 | Use P/N 7398 | call |
| 6688 | Use P/N 7397 | call |
| 6689 | Rear hub only 81,83-84 | $282.00 |
| 6696 | Spacer-sprocket bolt | $6.26 |
| 6702 | Bush for brake lever | $6.26 |
| 6703 | Rear brake rod | $31.00 |
| 6705 | Chain adjuster | $20.60 |
| 6709 | Use P/N 3188 | call |
| 6711 | Rear brake plate cpl | $160.80 |
| 6713 | Use P/N 6508 | call |
| 6714 | Tank decal left 1981 | $8.25 |
| 6715 | Tank decal right 1981 | $8.25 |
| 6720 | Seat base | $68.00 |
| 6721 | Seat bracket | $28.80 |
| 6722 | Holding loop | $17.60 |
| 6723 | Seat cpl low 81-82 | $121.00 |
| 6724 | Seat foam (low) 81-82 | $109.00 |
| 6725 | Seat cover 81-82 | $59.90 |
| 6729 | Hook | $3.52 |
| 6730 | Side panel decal R | $5.50 |
| 6731 | Foot peg left | $37.95 |
| 6735 | Foot peg right | $36.10 |
| 6738 | Foot peg bush | $10.00 |
| 6739 | Foot rest spring left | $6.16 |
| 6740 | Foot peg spring right | $6.16 |
| 6741 | Head stay L 250 | $12.80 |
| 6742 | Head stay R 250 | $12.80 |
| 6743 | Air box Red 1981 | $99.00 |
| 6746 | Use P/N 99033 (PR) | call |
| 6749 | Use P/N 99033 (PR) | call |
| 6750 | Spacer 8.5x12x12 | $4.40 |
| 6752 | Side panel decal L | $5.50 |
| 6753 | Intake tube 490 | $47.50 |
| 6785 | Kick pinion 1982 | $116.50 |
| 6786 | Spring cup | $7.08 |
| 6788 | Cylinder 250 cpl 81-82 | $578.90 |
| 6789 | Cylinder sleeve 250 81-82 | $241.50 |
| 6791 | Cylinder head 250 81-82 | $181.00 |
| 6792 | Cylinder head gasket 250 81-83 | $21.71 |
| 6793 | Cylinder base gasket 0.3 thick | $13.91 |
| 6794 | Cylinder head gasket 0.5 thick | $8.40 |
| 6795 | Cylinder head gasket 0.7 thick | $11.00 |
| 6796 | Reed valve cpl | $142.44 |
| 6797 | Reed valve body | $118.85 |
| 6798 | Reed valve pedal | $9.90 |
| 6799 | Reed valve stop | $17.95 |
| 6800 | Clutch housing 250 | $269.90 |
| 6803 | Primary chain single row | $43.60 |
| 6806 | Handle bar bushing | $6.93 |
| 6810 | Intake reed gakset | $4.40 |
| 6813 | Use P/N 6813W | call |
| 6813W | Piston 86.42 Wiseco | $218.00 |
| 6814 | Piston ring Std. 86.5 | $74.95 |
| 6814W | Piston ring 86.50 Wiseco | $20.00 |
| 6815 | Piston 1st oversize 86.64 | $231.31 |
| 6816 | Piston 2nd oversize 86.84 | $231.31 |
| 6817 | Use P/N 6819W | call |
| 6817W | Piston 86.92 Wiseco | $231.31 |
| 6818 | Piston 4th oversize 87.24 | $231.31 |
| 6819 | Piston 5th oversize 87.44 | $231.31 |
| 6819W | Piston 87.42 Wiseco | $231.31 |
| 6819.1W | Piston 87.92 Wiseco | $231.31 |
| 6819.2W | Piston 88.42 Wiseco | $231.31 |
| 6820 | Piston ring 1st oversize 86.7 | $86.59 |
| 6821 | Piston ring 2nd oversize 86.90 | $86.59 |
| 6822 | Piston ring 3rd oversize 87.10 | $86.59 |
| 6822W | Piston ring 87.00 Wiseco | $20.85 |
| 6824 | Piston ring 5th oversize 87.50 | $86.59 |
| 6824W | Piston ring 87.50 Wiseco | $20.85 |
| 6824.1W | Piston ring 88.33 Wiseco | $20.85 |
| 6824.2W | Piston ring 88.50 Wiseco | $20.85 |
| 6824.3W | Piston ring 89.00 Wiseco | $20.85 |
| 6826 | Crankshaft sprocket 250 | $62.70 |
| 6827 | Crankshaft sprocket 490 | $62.70 |
| 6828 | Fork wiper 42mm | $25.50 |
| 6844 | Exhaust pipe 400/490 | $430.00 |
| 6851 | Exhaust packing | $24.35 |
| 6866 | Exhaust spring | $5.97 |
| 6893 | Exhaust flange cpl 490 | $58.80 |
| 6904 | Carburetor cpl Bing 490 | $232.40 |
| 6905 | Carburetor cpl Bing 250 | $238.40 |
| 6906 | Vaporizer No. 7 | $8.91 |
| 6908 | Choke piston | $14.00 |
| 6909 | Spring 60-179 | $2.20 |
| 6910 | Choke housing | $6.71 |
| 6911 | Rubber cap 80-725 | $2.90 |
| 6912 | Choke lever 58-985 | $15.66 |
| 6913 | Screw 40-566 | $0.88 |
| 6914 | Nut 42-502 | $0.44 |
| 6915 | Floater cap | $32.68 |
| 6918 | Piston std. 66.95 Wiseco | $184.85 |
| 6918W | Piston 66.95 Wiseco | $184.85 |
| 6919 | Use P/N 523 | call |
| 6920 | Use P/N 6920W | call |
| 6920W | Piston 67.20 Wiseco | $184.85 |
| 6921 | Use P/N 6922W | call |
| 6922 | Piston 4th oversize 67.55 | $219.00 |
| 6922W | Piston 67.45 Wiseco | $184.85 |
| 6923 | Piston 67.75 Wiseco | $184.85 |
| 6923W | Piston 67.70 Wiseco | $184.85 |
| 6924 | Use P/N 6184 | call |
| 6925 | Use P/N 6187 | call |
| 6929 | Piston ring 5th oversize 67.95 | $217.00 |
| 6929W | Piston 67.95 Wiseco | $184.85 |
| 6929.1W | Piston 68.20 Wiseco | $184.85 |
| 6929.2W | Piston 68.45 Wiseco | $184.85 |
| 6929.3W | Piston 68.95 Wiseco | $184.85 |
| 6932 | Oval head screw M 3x10 | $0.46 |
| 6938 | Cylinder cpl 490 | $356.00 |
| 6940 | Cylinder sleeve 490 | $188.90 |
| 6941 | Cylinder head 490 | $195.90 |
| 6942 | Cylinder head gasket 81-82 490 | $26.60 |
| 6991 | O-ring 30x4 | $2.20 |
| 7303 | Chain protector | $40.00 |
| 7340 | Fender rear Enduro | $131.00 |
| 7397 | Rear spoke short 4.5x4x163 81-85 | $4.26 |
| 7398 | Rear spoke long 4.5x4x209 81-85 | $3.99 |
| 7400 | Frame cpl 1982 | $276.00 |
| 7409 | Thrust washer | $3.46 |
| 7413 | Swing arm 1982 | $271.10 |
| 7422 | Joint fork cpl | $83.50 |
| 7423 | Fork joint | $74.50 |
| 7424 | Linkage bushing 16x18x15 | $8.30 |
| 7425 | Use P/N 7426 | call |
| 7426 | Linkage arm 1982 | $80.10 |
| 7427 | Spherical bearing | $80.80 |
| 7428 | Distance bush 11x16x56 | $7.10 |
| 7429 | Support loop | $9.35 |
| 7430 | Screw socket 19 | $20.62 |
| 7431 | Joint bolt | $17.96 |
| 7432 | Distance bushing 12x16x36 | $7.69 |
| 7433 | Air filter cover plate | $6.71 |
| 7435 | Air filter frame | $44.00 |
| 7436 | Air filter 82-on | $23.40 |
| 7437 | Filter holding wire | $25.00 |
| 7438 | Air filter box 1982 | $114.50 |
| 7442 | Clamp | $2.62 |
| 7446 | Side panel, left 1982 | $40.10 |
| 7450 | Side panel right 1982 | $40.10 |
| 7451 | Use P/N 348 | call |
| 7461 | Cylinder head gasket 490 83-84 | $20.90 |
| 7462 | Cylinder base gasket 0.3 | $12.40 |
| 7463 | Cylinder base gasket 0.5 | $7.80 |
| 7464 | Cylinder base gasket 0.7 | $9.40 |
| 7465 | Intake elbow 490 ALUM | $60.70 |
| 7466 | Intake flange 1983 Enduro ALUM | $80.56 |
| 7467 | Intake flange 490 rubber | $83.10 |
| 7470 | Intake flange 250 ALUM | $59.60 |
| 7472 | Front fork cpl | $1108.00 |
| 7474 | Tripple clamp upper | $138.15 |
| 7475 | Damper tube soldered | $39.55 |
| 7477 | Damper tube cpl | $49.66 |
| 7478 | Damper cpl | $91.06 |
| 7479 | Rebound spring hard | $4.90 |
| 7480 | Fork leg cpl | $411.10 |
| 7481 | Fork spring | $43.65 |
| 7483 | Use P/N 10100 | call |
| 7484 | Steering stem clip | $1.10 |
| 7486 | Crankcase right | $376.20 |
| 7488 | Crankcase left | $347.00 |
| 7489 | Use P/N 1993 | call |
| 7490 | Plug | $0.66 |
| 7500 | Rear hub 1982 | $217.10 |
| 7502 | Brake cam | $40.90 |
| 7504 | Brake plate R bare 1982 | $125.50 |
| 7505 | Pivot bolt | $11.40 |
| 7506 | Sliding bush | $14.00 |
| 7507 | Brake plate cpl R 1982 | $145.00 |
| 7508 | Bearing bush | $15.00 |
| 7514 | Sprocket 56T | $72.00 |
| 7515 | Nilos ring | $4.40 |
| 7516 | Chain adjuster | $17.15 |
| 7518 | Chain adjuster | $39.80 |
| 7519 | Rear axle 1982 | $43.30 |
| 7521 | Sprocket steel 54T thru 85 | $67.60 |
| 7527 | Rear brake arm | $51.15 |
| 7531 | Foot brake pedal | $47.85 |
| 7535 | Bearing bush | $5.94 |
| 7536 | Rear brake rod | $12.75 |
| 7537 | Nipple holder | $7.26 |
| 7538 | Brake adjust nut 1982 | $4.95 |
| 7539 | Bearing bush | $7.48 |
| 7541 | Brake rod | $21.80 |
| 7544 | Alpha control decal 1982 | $4.40 |
| 7545 | Fork bolt | $12.75 |
| 7546 | Shock bolt lower | $9.80 |
| 7547 | Washer | $6.26 |
| 7548 | Shim | $1.10 |
| 7549 | Shim | $1.10 |
| 7550 | Foam seal ring | $2.75 |
| 7555 | Chain guide plate R | $9.90 |
| 7556 | Roller chain | $9.35 |
| 7557 | Chain guide spacer bush | $4.95 |
| 7558 | Chain guide spacer | $4.62 |
| 7559 | Sliding washer | $9.35 |
| 7560 | Swing arm pad | $13.00 |
| 7562 | Bearing piece | $3.74 |
| 7563 | Plug | $0.88 |
| 7589 | Brake plate | $50.80 |
| 7590 | Use P/N 6508 | call |
| 7599 | Internal motoplat w/o coil | $331.00 |
| 7618 | Steering head nut | $10.50 |
| 7619 | Fork spring | $44.00 |
| 7840 | Swing arm 1983 | $325.00 |
| 7841 | Chain adjuster | $15.85 |
| 7845 | Joint fork | $107.95 |
| 7846 | Bearing bush | $8.48 |
| 7847 | Bushing | $11.75 |
| 7848 | Use P/N 7849 | call |
| 7849 | Linkage are 83-84 | $69.65 |
| 7850 | Grease nipple | $1.76 |
| 7851 | Hinge bush 10x14x22 | $9.79 |
| 7852 | Use P/N 8858 | call |
| 7853 | Seal ring | $4.66 |
| 7854 | Fork bolt | $25.90 |
| 7855 | Socket screw M 12x70 | $3.96 |
| 7856 | Hinge bearing bolt | $19.70 |
| 7857 | Distance bushing 11x16x40 | $8.95 |
| 7858 | Support Loop | $9.35 |
| 7860 | Use P/N 8513 | call |
| 7861 | Swing arm pad | $10.52 |
| 7863 | Swing arm plug | $0.88 |
| 7864 | Chain guide spacer | $5.50 |
| 7886 | Sprocket 52T | $69.00 |
| 7889 | Decompression lever assy. | $14.78 |
| 7890 | Screw nipple | $1.67 |
| 7891 | Clutch lever cover | $6.60 |
| 7892 | Use P/N 9351 | call |
| 7894 | Use P/N 9352 | call |
| 7895 | Use P/N 99044 | call |
| 7896 | Use P/N 6669 | call |
| 7898 | Use P/N 8521 | call |
| 7901 | Spacer bush for brake plate | $6.28 |
| 7902 | Brake plate cpl | $168.45 |
| 7903 | Rear axle 83-84 | $40.00 |
| 7907 | Rear wheel spacer 15.0 | $11.20 |
| 7910 | Rear brake pedal 83-84 | $38.40 |
| 7917 | Hexagon screw M 8x100 | $3.30 |
| 7921 | Use P/N 1598 | call |
| 7922 | Brake lever spring | $16.95 |
| 7924 | Use P/N 6508 | call |
| 7927 | Tank decal L 1983 EUROPE | $11.00 |
| 7928 | Tank decal R 1983 EUROPE | $11.00 |
| 7935 | Cylinder head stay | $22.00 |
| 7936 | Rear brake rod | $21.50 |
| 7937 | Blind rivet 3.2x10 | $0.99 |
| 7938 | Use P/N 7950T | call |
| 7939 | Spacer bush | $2.31 |
| 7942 | Seat cpl 1983 | $128.00 |
| 7943 | Seat foam-low 1983 | $80.70 |
| 7944 | Seat cover Red 1983 | $62.50 |
| 7948 | Use P/N 7988 | call |
| 7949 | Cylinder head stay | $15.40 |
| 7950 | Clutch cable cpl thru 82 | $23.53 |
| 7950T | Terrycable clutch cable 1983-on | $32.95 |
| 7951 | Clutch cable nipple | $3.95 |
| 7954 | Throttle cable 1983-on | $16.33 |
| 7954T | Terrycable throttle cable 1983-on | $32.95 |
| 7957 | Spoke 4x3.5x4x230-80º | $3.63 |
| 7958 | Spoke 4x3.5x4x230-100º | $3.63 |
| 7968 | Clamp | $10.22 |
| 7969 | Air box 83-84 | $169.00 |
| 7971 | Side panel L. 1983 | $65.00 |
| 7972 | Side panel R. 1983 | $65.00 |
| 7973 | Intake air boot | $43.95 |
| 7975 | Front No. plate decal Green 83-86 | $3.95 |
| 7977 | Decal L green | $3.95 |
| 7978 | Decal LS panel 1983 | $4.40 |
| 7980 | Decal R Green | $3.95 |
| 7981 | Decal RS panel 1983 | $4.40 |
| 7983 | Front decal Yellow 1983 | $6.60 |
| 7988 | Spash guard rear | $23.00 |
| 7990 | Chain roller cpl | $38.50 |
| 7991 | Chain roller cpl | $20.30 |
| 7992 | Spacer bush | $3.60 |
| 7993 | Ball bearing 608 2 RS | $11.02 |
| 7994 | Loop | $7.48 |
| 7996 | Use P/N 1749 | call |
| 8008 | Bearing lock plate | $4.40 |
| 8009 | Thrust plate | $4.30 |
| 8010 | Lock plate | $1.36 |
| 8011 | Chain guard plate | $22.34 |
| 8012 | Spacer bush | $3.54 |
| 8014 | Return spring pin | $7.18 |
| 8016 | Stop plate | $5.72 |
| 8018 | Crankcase R 250 | $286.00 |
| 8020 | Crankcase L 250 | $324.00 |
| 8021 | Crankcase gasket | $8.36 |
| 8023 | Clutch case gasket | $8.36 |
| 8024 | Clutch cover 250/490 | $208.90 |
| 8025 | Oil plate | $5.72 |
| 8026 | Crankcase L 490 | $413.50 |
| 8027 | Crankcase R 490 | $363.45 |
| 8029 | Crankcase left | $355.50 |
| 8030 | Crankcase gasket | $8.36 |
| 8031 | Oil plate | $5.28 |
| 8032 | Swing arm bush | $10.92 |
| 8049 | Crankshaft gear 24T | $115.13 |
| 8057 | Crankshaft seal 250 | $13.02 |
| 8067 | Needle bearing 25x31x20 | $34.95 |
| 8070 | Crankshaft gear 31T | $83.75 |
| 8071 | Clutch spring 490 | $5.50 |
| 8072 | Washer 18x25x0.5 | $0.67 |
| 8077 | Cover plate | $18.90 |
| 8079 | Needle cage | $13.00 |
| 8082 | Fiber clutch plate | $19.30 |
| 8083 | Use P/N 9450 | call |
| 8084 | Pressure plate | $81.50 |
| 8087 | Clutch bearing | $35.90 |
| 8089 | Clutch push rod | $9.65 |
| 8091 | Needle roller | $0.88 |
| 8092 | Clutch nut lock tab | $4.75 |
| 8094 | Clutch gear 66T 490 | $193.86 |
| 8096 | Clutch housing only 490 | $181.60 |
| 8100 | Clutch body | $62.50 |
| 8101 | Clutch housing cpl 490 | $252.00 |
| 8102 | Rubber cushion | $4.96 |
| 8105 | Clutch spring bolt | $9.60 |
| 8106 | Clutch spring 250 | $3.44 |
| 8121 | Bearing op shaft 3205 2 RS C 3 2 | $52.02 |
| 8126 | Ball bearing mainshaft 6204 ZC 3 | $14.00 |
| 8144 | Mainshaft 14T D | $139.33 |
| 8145 | 2nd gear MS 17T D | $130.44 |
| 8146 | 3rd gear MS 20T D | $139.33 |
| 8147 | 4th gear MS 23T CD | $131.44 |
| 8148 | 5th gear MS 25T C1 | $131.44 |
| 8152 | 1st gear OP 33T D | $131.44 |
| 8153 | 2nd gear OP 29T CD | $131.44 |
| 8154 | 3rd gear OP 26T C | $131.44 |
| 8155 | 4th gear OP 24T CD | $139.33 |
| 8156 | 5th gear OP 21T D3 | $139.33 |
| 8160 | Use P/N 8847 | call |
| 8162 | Use P/N 8807 | call |
| 8164 | Kickstarter joint | $83.40 |
| 8165 | Kick pivot bolt | $18.46 |
| 8171 | Kick ratchet | $124.60 |
| 8172 | Pressure spring for kickstarter gear | $12.98 |
| 8173 | Spring cup | $1.98 |
| 8174 | Kickstarter return spring | $10.80 |
| 8175 | Oil seal 18x24x3 | $5.80 |
| 8176 | Thrust washer | $5.70 |
| 8177 | Kick shaft bearing | $9.80 |
| 8184 | Shift crank | $78.68 |
| 8185 | Shift lever 83-86 | $49.40 |
| 8187 | Shift shaft 83-86 | $96.69 |
| 8191 | Shift drum 250 | $197.13 |
| 8194 | Stud | $3.96 |
| 8195 | Shift return spring | $15.49 |
| 8197 | Shift ratchet dog | $18.40 |
| 8198 | Spring pin | $5.60 |
| 8199 | Washer | $2.20 |
| 8200 | Pressure spring | $0.79 |
| 8201 | Shift fork spindle | $19.50 |
| 8204 | Pawl screw | $15.78 |
| 8205 | Detent spring | $1.32 |
| 8206 | Detent pin | $17.20 |
| 8207 | Shifting cam cover plate | $19.60 |
| 8208 | Stop plate | $6.70 |
| 8209 | Securing plate | $3.30 |
| 8213 | Shift drum 5 spd | $194.00 |
| 8214 | Shift fork A5 | $70.10 |
| 8215 | Shift fork H5 | $61.00 |
| 8216 | Shift drum 490 | $197.75 |
| 8217 | Shifting drum | $192.00 |
| 8218 | Cylinder cpl 250 | $626.25 |
| 8220 | Cylinder sleeve 250 | $198.85 |
| 8221 | Cylinder head 250 | $193.17 |
| 8222 | Cylinder base gasket 0.3mm | $10.20 |
| 8223 | Cylinder base gasket 0.5mm | $7.80 |
| 8224 | Cylinder base gasket 0.7mm | $9.40 |
| 8228 | Main shaft 15t C | $248.30 |
| 8229 | 2nd gear MS 18T C | $112.63 |
| 8230 | 3rd gear MS 21T C | $138.33 |
| 8231 | Use P/N 8147 | call |
| 8232 | 5th gear MS 25T C1 | $107.08 |
| 8233 | Circlip | $0.88 |
| 8234 | Thrust washer 18x25x1 | $2.88 |
| 8235 | Circlip D 21x1.2 | $1.02 |
| 8237 | Output shaft | $137.13 |
| 8238 | 1st gear OP 31T C | $130.44 |
| 8239 | 2nd gear OP 29T CD | $99.15 |
| 8240 | 3rd gear OP 26T C | $114.15 |
| 8241 | 4th gear OP 24T CD | $144.14 |
| 8242 | 5th gear OP 22T CD1 | $114.76 |
| 8243 | Washer 18x27x1 | $2.77 |
| 8244 | Spacer washer | $1.32 |
| 8245 | O-ring | $0.88 |
| 8246 | Needle bearing only | $11.60 |
| 8247 | Needle bearing w/ring 18x26x13 | $28.90 |
| 8248 | Spacer | $13.40 |
| 8249 | Sprocket 12T | $25.50 |
| 8250 | Sprocket 13T | $25.50 |
| 8251 | Sprocket 14T | $25.50 |
| 8252 | Sprocket 15T | $18.00 |
| 8253 | Washer 18x25x1 | $0.88 |
| 8254 | Crankshaft cpl 250 | $314.00 |
| 8255 | Crankshaft nut SW 32 | $12.30 |
| 8260 | Inner ring 25x31.45x17.5 | $30.78 |
| 8263 | Sprocket 16T | $17.40 |
| 8265 | Kicistarter idle gear | $68.34 |
| 8266 | Needle bearing 18x22x100 | $15.93 |
| 8267 | Kickstarter shaft | $103.54 |
| 8268 | Circlip 18x1.2 | $0.77 |
| 8269 | Kickstarter ratchet gear cpl | $149.60 |
| 8270 | Use P/N 8269 | call |
| 8273 | Clutch housing cpl 250 | $257.30 |
| 8274 | Clutch housing only | $111.32 |
| 8275 | Clutch gear 69T 250 | $202.88 |
| 8276 | Inner ring | $36.65 |
| 8277 | Clutch washer | $13.50 |
| 8278 | Hexagon nut M 16x1.0 | $4.90 |
| 8279 | Clutch lever welded | $116.50 |
| 8283 | Clutch return spring | $5.52 |
| 8284 | Crankshaft cpl 490 | $498.90 |
| 8290 | Inner ring 25x31.45x13 | $27.60 |
| 8295 | Cylinder cpl 400 | $833.90 |
| 8297 | Cylinder sleeve 490 83-84 | $204.00 |
| 8298 | Decompression rel valve cpl | $109.95 |
| 8301 | Cylinder head 490 | $130.20 |
| 8302 | Cylinder cpl 490 | $833.90 |
| 8303 | Seal ring 18x22 | $1.54 |
| 8306 | Mainshaft 15T F | $183.45 |
| 8307 | 2nd gear MS 18T F | $104.30 |
| 8310 | Thrust washer 21.5x31.5x1 | $2.42 |
| 8311 | Thrust washer 18x24x1 | $2.37 |
| 8312 | Inner ring 21.5x25x13 | $19.57 |
| 8313 | Needle bearing 25x29x13 | $24.00 |
| 8315 | Output shaft 4 spd | $119.70 |
| 8316 | 1st gear OP 31T F | $130.60 |
| 8317 | 2nd gear OP 28T F | $130.60 |
| 8320 | Needle cage K 18x24x12 | $24.47 |
| 8321 | Spacer bush | $3.08 |
| 8324 | Carburetor 250 | $219.77 |
| 8325 | Carbuteror cpl V54-2 0 40 490 | $219.77 |
| 8326 | Vaporized No. 5 | $9.32 |
| 8327 | Jet needle 4K2 | $6.60 |
| 8329 | 3rd gear OP 25T FL1 | $103.50 |
| 8332 | 4th gear MS 24T FL | $103.73 |
| 8335 | 4th gear OP 23T F | $121.90 |
| 8340 | 3rd gear MS 21T FL | $117.35 |
| 8353 | Exhaust welded 250 | $368.53 |
| 8366 | Silencer cpl 250 | $177.94 |
| 8368 | Securing ring 67x2.5 | $4.40 |
| 8370 | Piston cpl 66.97 | $205.11 |
| 8371 | Piston pin 18x13x50 | $21.03 |
| 8372 | Piston cpl 67.17 | $161.00 |
| 8373 | Piston cpl 67.37 | $161.00 |
| 8374 | Piston cpl 67.57 | $161.00 |
| 8375 | Use P/N 8375W | call |
| 8375W | Piston 67.72 | $193.50 |
| 8376 | Use P/N 8376W | call |
| 8376W | Piston 67.97 | $193.50 |
| 8376.1W | Piston 68.22 | $193.50 |
| 8376.2W | Piston 68.47 | $193.50 |
| 8377 | Clamp S40/15 SKZ | $6.86 |
| 8379 | Exhaust welded 490 | $368.53 |
| 8382 | Silencer cpl 490 | $178.38 |
| 8450 | 4th gear OP 23T FK | $121.85 |
| 8451 | 3rd gear MS 21T FK | $116.25 |
| 8452 | 4th gear MS 23T FK | $114.40 |
| 8453 | 3rd gear OP 26T FK | $120.70 |
| 8476 | Counter holder for clutch | $45.80 |
| 8486 | Flange nut M 16x1.5 | $6.84 |
| 8492 | Tension pad | $13.40 |
| 8493 | Chain guide plate | $8.80 |
| 8501 | Wrist pin 18x46 | $23.60 |
| 8505 | Cylinder sleeve 250 1984 | $205.84 |
| 8506 | Reed valve tongue | $12.42 |
| 8507 | Frame SC490 1984 | $503.60 |
| 8510 | Swing arm 250/490 1984 | $275.00 |
| 8513 | Chain guide cpl | $76.65 |
| 8514 | Chain guide pads | $9.90 |
| 8515 | Guide roller bushing | $7.86 |
| 8516 | Spacer-upper | $7.86 |
| 8519 | Use P/N 6669 | call |
| 8521 | Throttle cpl 314 | $39.95 |
| 8522 | Clutch lever cpl | $40.70 |
| 8523 | Brake lever cpl | $44.20 |
| 8524 | Flat head screw M 5x20 | $0.44 |
| 5302272 | Needle jet 272.2 | $6.34 |
| 5302276.2 | Needle jet 276.2 | $6.34 |
| 5302278.2 | Needle jet 278.2 | $6.82 |
| 5302280.2 | Needle jet 280.2 | $6.34 |
| 5302282.2 | Needle jet 282.2 | $6.92 |
| 53022274.2 | Needle jet 274.2 | $6.34 |
1,654 parts total — To order, call (805) 469-0477 or email [email protected]
